Systron WM
Washing MachinesVertical washing and drying station built for Low E and coated glass, with stainless steel construction and washing speeds up to 10 m per minute.
Specifications
- Type
- Washing and drying station
- Washing speed
- Up to 10 m/min
- Water tanks
- 2, each with a 6 kW heating element
- Glass thickness
- Automatic adjustment without loss of cycle time
- Maximum pane size
- 2500, 2700, 3500, 5000, 6000 or 9000 mm (configurable)
Brochures
About the Systron WM
The Systron WM is a vertical washing and drying machine for flat glass processing companies with the highest demands. Its solid construction, high quality components and special transport system make it especially suited to low E glass.
The washing section is divided into two zones, a pre wash zone and a main wash zone. The pre wash zone has one pair of brushes and four spray tubes, and the main wash zone has two pairs of brushes and four spray tubes. The machine adjusts automatically to the glass thickness with no loss of cycle time, washing at up to 10 m per minute, and the intuitive graphical interface keeps operation simple.
In the final step the glass passes through the drying zone, where a high performance blower ensures crystal clear visibility and a guaranteed dry result.
Highlights:
- Machine body and doors made of stainless steel, so no corrosion can occur
- Completely enclosed system protected from sunlight, preventing algae formation
- Six low E brushes across two washing zones
- Special transport system with no mechanical contact on glass coatings
- Complete drive technology in the dry area of the machine roof
- Two water tanks, each with an integrated 6 kW heating element
Watch
The Systron WM in action
