Systron LOOP
Edging & PolishingVertical straight line edging system with 11 cup wheel spindles, grinding and polishing straight special shapes in very little floor space.
Specifications
- Type
- Vertical straight line edging system with cup wheels
- Spindles
- 11
- Passes
- 4 (automatic 90 degree rotation each pass)
- Maximum pane size
- 3500, 5000, 6000 or 9000 mm (configurable)
- Feed
- Servo controlled, with polishing pressure control
Brochures
About the Systron LOOP
The Systron LOOP vertical edging system was developed specially for the requirements of the glass industry. The glass passes through four rounds on the straight line edger, rotating 90 degrees automatically on each pass. Grinding and polishing are carried out by 11 spindles with cup wheels, so even large and heavy special shapes can be processed very efficiently while using very little floor space.
To manufacture dimensionally accurate and angularly precise products that also need internal machining, the LOOP is best combined with the Systron proHD glass processing centre. The two systems can also run independently of each other.
Systron introduces new standards:
- Premium straight line edging machine with 11 spindles
- Servo controlled spindle feed and polishing pressure control
- Corner dubbing by a circumferential tool
- Integrated bottom edge washing machine
The intuitive machine software is shown clearly on a multi touch panel, and a new operating concept allows fast, accurate axis positioning in manual mode. A digital twin gives a real time, exact reflection of the machine on the operator terminal for easy operation and overview.
LOOP highlights:
- Machining of straight special shapes with cup wheel polishing
- No set up times for different glass dimensions
- Simple and reliable transport system
- High polishing quality through constant, servo controlled polishing pressure
- Easy to adapt to the available space thanks to the modular design
- Flexible, strong turning unit for large and heavy special shapes
The LOOP proHD Combo pairs the LOOP with the proHD for products that are true to size and angle with a brilliant cup wheel polish:
- Cup wheel grinding and polishing
- Pre grinding true to size, plus internal machining of any kind
- Very short cycle times with small batch sizes
- High dimensional and angular accuracy, even with straight special shapes
- Vertical, space saving design
- Option to machine complex CNC glass with the proHD by bypass
